Overview

The X1501P-4T1T is a high-performance outdoor Gigabit PoE switch engineered for bandwidth-intensive applications in harsh environments. Encased in a rugged, weatherproof (IP67-rated) metal housing, it delivers reliable operation under extreme temperatures, rain, dust, and physical stress – ideal for industrial sites, smart city deployments, and remote surveillance systems where both speed and environmental resilience are critical.

This compact switch features four Gigabit (10/100/1000Mbps) PoE+ ports, each capable of delivering up to 30W (IEEE 802.3af/at) to power high-definition IP cameras, wireless access points, or IoT sensors. A dedicated Gigabit (10/100/1000Mbps) RJ45 uplink port ensures high-bandwidth connectivity back to the network core, eliminating bottlenecks for data-intensive tasks. With a total PoE budget of 75W and intelligent power management, the switch optimizes power allocation across connected devices.

Designed for global deployment, the X1501P-4T1T accepts a universal AC input (110–240V) and delivers stable 52V DC PoE output. Its plug-and-play operation, combined with Gigabit throughput and industrial-grade durability, streamlines installations while future-proofing outdoor networks for evolving bandwidth demands.

Key Features

1. Gigabit PoE+ Performance – Four 10/100/1000Mbps ports deliver up to 30W per port (IEEE 802.3af/at), supporting high-bandwidth devices like 4K cameras and dual-band APs.

2. High-Speed Uplink – Dedicated 1x Gigabit (10/100/1000Mbps) RJ45 uplink port ensures sufficient backhaul capacity for data-intensive applications.

3. Industrial Outdoor Design – IP67-rated metal housing protects against water, dust, corrosion, and extreme temperatures (-40°C to 75°C).

4. Optimized 75W Power Budget – Intelligent per-port power allocation maximizes efficiency while supporting PoE+ devices.

5. Universal Power & Thermal Management – Wide AC input (110–240V) with 52V DC PoE output + built-in thermal protection for stable global operation.
