1) 100Mbit each port
2) DC Jack:5.5*2.1mm（DC Jack:5.5*2.5mm / Type-C / Micro-USB connector available to choose）
3) IEEE802.3at/af Standard
4) PoE/IN:44-57V(30W)
5) ModeA or ModeB ISO:1.5KV
6) DC/OUT:12V/2A(24W)
7) Size: 81*28*24mm
8) total power:24W
9) 1500V high voltage isolation
10)The PS5712AT normal version use for 4.5 inch PTZ. The PS5712AT high-effect version use for 6 inch PTZ

*The Main Board of this PoE Splitter is 12V 2A Output High-effect Version.

*Data Transfer Rate is 10/100bps.

*2 Interface Connection Methods for You to Choose :

DC Jack 5.5*2.1mm (XPS5712 High-effect Version-DC55*21)

DC Jack 5.5*2.5mm (XPS5712AT High-effect Version-25 DC55*25)
