Overview

The X1501P-8T is a high-density outdoor Power over Ethernet (PoE) switch designed for cost-effective deployment of power and data in harsh environments. Encased in a rugged IP67-rated metal housing, it delivers reliable operation in extreme temperatures (-40°C to 75°C), heavy rain, dust, and corrosive conditions – ideal for industrial IoT networks, surveillance clusters, and distributed wireless systems where concentrated device connectivity is critical.

Featuring eight 10/100Mbps Fast Ethernet PoE+ ports, each capable of delivering up to 30W (IEEE 802.3af/at), this switch powers devices like IP cameras, wireless APs, and access control systems while simplifying cabling. With a robust 120W total PoE budget and intelligent power allocation, it ensures stable operation across all connected devices. Advanced 6KV surge protection guards against lightning strikes and power fluctuations – a critical feature for exposed outdoor installations.

Designed for flexible deployment, the X1501P-8T supports universal AC input (110–240V) and outputs efficient 52V DC power. Its integrated wall-mount and pole-mount brackets enable rapid installation on poles, walls, or trusses, reducing setup time and infrastructure costs in challenging outdoor environments.

Key Features

1. High-Density PoE+ Ports – 8× 10/100Mbps ports deliver ≤30W per port (IEEE 802.3af/at) for cameras, APs, and sensors.

2. Industrial Weatherproofing – IP67-rated metal enclosure resists water, dust, corrosion, and extreme temperatures (-40°C to 75°C).

3. 6KV Lightning Protection – Integrated surge protection on all ports safeguards against voltage spikes from storms/power faults.

4. Flexible Mounting – Built-in brackets for wall/pole mounting simplify installation in diverse outdoor scenarios.

5. Optimized Power Delivery – 120W total PoE budget + wide AC input (110-240V) with stable 52V DC output.
