Model: X-SFP-10G-ER

Data Rate: 10G

Wavelength: 1550nm

Distance: 40KM

Connector: LC

Fiber Type: SM

DDM: YES

Overview

10G SFP+ ER 1310nm 40KM LC Optical Transceiver is a high-performance, hot-pluggable module designed for 10 Gigabit Ethernet long-haul applications.

Operating at a wavelength of 1310nm, it achieves extended reach up to 40 kilometers over single-mode fiber (SMF), ideal for metro networks, cross-campus links, and telecom backbone systems. Compliant with IEEE 802.3ae 10GBASE-ER standards and SFF-8431 specifications, it ensures reliable interoperability with industry-leading network equipment.

Featuring an LC duplex connector, the transceiver delivers superior signal integrity, low power consumption, and integrated Digital Diagnostics Monitoring (DDM) for real-time performance tracking and fault detection. Its compact SFP+ design and industrial temperature range (-40°C to 85°C) support deployment in challenging environments. Combining robust performance, energy efficiency, and scalability, this transceiver is a cost-effective solution for high-speed, ultra-long-distance optical connectivity.

Features

Hot-pluggable SFP+ footprint

Supports 9.5 to 10.3Gb/s bit rates

Single 3.3V power supply

Maximum link length of 40km

1550nm EML transmitter, PIN photo-detector

Duplex LC connector

Power dissipation < 1.5W

Built-in digital diagnostic functions

Case temperature range ：Standard:-5 to +70°C、Industrial:-40 to +85°C
